1 Watt Hand Carry Wireless Mesh Network Products IP Mesh Transmitter Harsh Area For Unmanned Vehicles

Brand Name : SUNTOR

Model Number : ST9601MS

Place of Origin : CHINA

MOQ : 1PAIR

Payment Terms : T/T, Western Union

Supply Ability : 10000set/month

Delivery Time : 10-15 work days

Packaging Details : CARTON

RF Power : 1W

Battery Endurance : 2 hours

Temperature : Storage: -30℃~+90℃/Working: -20℃~+65℃

Weight : 480g(Without Battery) Battery Weight: 340g

Serial Port : 1*Serial Port(On request)

Dimension : 141.5mm*88mm*30mm

Encryption : AES128

Power : DC9-28V

Contact Now

1 watt hand carry IP Mesh Solutions for Unmanned Vehicles and UAV wireless transmission



Datasheet



Introduction:



ST9601MS is a MIMO dual-band high bandwidth network wireless device, which can realize high-performance dedicated wireless network, has strong non-line-of-sight transmission capability, and supports mobile phones, computers and other terminal devices to access the network through 2.4GHz WiFi. At the same time, it can support GPS and it has specially design for portable applications. It is specially designed for Drone/UAV/Robot and UGV LOS and NLOS video and duplex bi-directional data transmitting.



Features:

  • Handcarry model
  • MIMO 2T2R
  • Plug and Play
  • Support GPS
  • 1KM distance in NLOS and challenging environment
  • Moving transmission
Working Frequency

570~590MHz/1400~1420MHz

590~1400MHz(On request)

 Bootloader U-boot
  2412-2462MHz(Wifi) Linux 3.18.19
  1559-1577MHz(GPS) Wired Network IP address configurable
Bandwidth 5/10/20MHz   Subnet Mask Configurable
  20MHz(Wifi) Wireless Network Working Frequency Adjustable
RF Power 1W   Bandwidth Adjustable
  0.2W(Wifi)   RF Power Adjustable
Receive Sensitivity -92dBm   Support Adhoc
  -90dBm(Wifi)   ESSID/BSSID Configurable
Duplex Mode TDD   Supports adaptive rate and fixed rate modes
Modulation BPSK/QPSK/16-QAM/64-QAM
Diversity Mode Transmitting and receiving diversity   Support Distance Optimization
Upstream and downstream bandwidth Two-way bandwidth up to 80Mbps   Support RTS/CTS Setting
  40Mbps(Wifi)   Connection Status Display
Antenna 2*N type Antenna Interface Wifi Working Frequency Adjustable
  1*Wifi SMA Antenna Interface   RF Power Adjustable
  1*GPS SMA Antenna Interface   Support AP mode
Ethernet 1*100Mbps Ethernet Interface   ESSID Configurable



Application:
